EMZ-5D + MA502 + BD-LED (7X – 45X) Stand Configuration System, Working Distance: 93mm (3.66″)

Description

Modular Flexibility:
EMZ Series zoom stereo microscopes are most the rugged microscopes from Japan and tailored to fit the needs of each and every customer. Modular design enables the user to engineer their own custom solution for virtually any application, selecting components from the widest range bodies, stands, eyepieces, supplementary lenses, illuminators, camera adapters, and accessory components available in the microscope industry today.

Superb Optics:
Multi-coated optical components, free form chromatic and spherical aberration, provide crystal-clear, high resolution images. The Greenough optical design provides superior erect, unreversed, stereoscopic images, rich in contrast, brightness and correct in their original color. Excellent depth of field and a flat image rendition are also characteristic of the EMZ Series product line.

Rugged Dependability:
All-metal aluminum alloy microscope bodies and components with chemical resistant finishes guarantee stability and rugged dependability for a lifetime of day-in and day-out use. Superior craftsmanship, quality components and materials result in long-lasting, high-performance products.

Ergonomic Design:
All EMZ Series zoom stereo microscope bodies feature a compact lightweight design. Every stereo body features adjustment diopter tubes and interpupillary distance adjustment. Observation tubes are inclined at 45°, 60° or 90° for convenient fatigue free viewing depending on the application, A range of fixed of tilting focus blocks are available to mount the microscope body onto existing O.E.M. equipment. A choice of Zoom, Turret or Fixed magnification bodies with various working distances, optional auxiliary objectives and eyepieces, multiple adjustable stands, versatile illumination systems, and auxiliary components allow the end user to design a system to fulfill their specific requirements.

Applications:
EMZ Series zoom stereo microscopes are the prefect modular microscope systems for a multitude of applications ranging from biological and industrial fields to educational and training situations. A wide variety of professional groups currently use the EM series product to their advantage: Biologist, Physicians, Geologists, Engineers, Dentists, Dental Technicians, Veterinarians, Paleontologists, Entomologists, Gemologists, Educators, Scientific Researchers, Quality Control Personnel, Quality Assurance Personnel, Assemblers, Forensic Document Examiners, Art Restoration Experts, Textile Specialists, Wire and Die Manufacturers, Environmental Specialists, Ophthalmic Specialists, Dermatologists, Metrology Personnel, Tool and Die Professionals, Circuit Board Rework and Repair Personnel, Aquaculture Professionals, Embryo Transplant Professionals, Horticultural Experts, Exterminators, Fish and Wildlife Departments, U.S. Customs Service, Semiconductor Manufacturers, Foresters, Pharmaceutical Manufacturers, Electroplating Specialist, Ballistics Experts, and more!

Additional information

Weight	1.0000 kg
Components & Accessories	Eyepieces Stands Focus Blocks Holder Auxiliary Lenses Illuminators Micrometer Lens Stages Polarizing Accessories Protective Glass Covers Microscopy Cameras C" Mounts/CameraAdapters Filters Accessories
Details	EM Series Optical Data Model Zoom Range Auxiliary Lens Working Distance (mm) SWF10X Eyepieces SWF12.5X Eyepieces SWF15X Eyepieces SWF20X Eyepieces SWF30X Eyepieces Total Mag. Field (mm) Total Mag. Field Diameter (mm) Total Mag. Field Diameter (mm) Total Mag. Field Diameter (mm) Total Mag. Field Diameter (mm) EMZ-1 1X -3X none 93 10X ~ 30X 23 ~ 7.7 12.5X ~ 37.5x 20 ~ 6.6 15X ~ 45X 15.4 ~ 5.1 20X ~ 60X 11.5 ~ 3.8 30X ~ 90X 7.7 ~ 2.5 0.3X 251 3X ~ 9X 76 ~ 25.6 3.75X ~ 11.25X 66 ~ 22 4.5X ~ 13.5X 51.3 ~ 17 6X ~ 18X 38 ~ 12.6 9X ~ 27X 25.5 ~ 8.3 0.44X 181 4.4X ~ 13.2X 52 ~ 17.5 5.5X ~ 16.5X 45 ~ 15 6.6X ~ 19.8X 35 ~ 11.5 8.8X ~ 26.4X 26 ~ 8.6 13.2X ~ 39.6X 17.5 ~ 5.6 0.5X 150 5X ~ 15X 46 ~ 15.3 6.25X ~ 18.75X 40 ~ 13.2 7.5X ~ 22.5X 30.6 ~ 10.2 10X ~ 30X 23 ~ 7.6 15X ~ 45X 15.4 ~ 5 0.75X 97 7.5X ~ 22.5X 30.6 ~ 10.2 9.37X ~ 28.1X 26.6 ~ 8.8 11.25X ~ 33.75X 20.5 ~ 6.8 15 ~ 45X 15 ~ 5.0 22.5X ~ 67.5X 10.2 ~ 3.3 1.5X 49 15X ~ 45X 15.3 ~ 5.1 18.75X ~ 56.25X 13.3 ~ 4.4 22.5X ~ 67.5X 10.2 ~ 3.4 30X ~ 90X 7.7 ~ 2.5 45X ~ 135X 5.1 ~ 1.6 2.0X 34 20X ~ 60X 11.5 ~ 3.8 25X ~ 75X 10 ~ 3.3 30X ~ 90X 7.7 ~ 2.6 40X ~ 120X 5.7 ~ 1.9 60X ~ 180X 3.8 ~ 1.2 EMZ-2 EMZ-2TR EMZ-5 EMZ-5TR EMZ-9 0.7X~ 4.5X none 93 7X ~ 45X 32.8 ~ 5.1 8.75X ~ 56.25X 28.5 ~ 4.4 10.5X ~ 67.5X 22 ~ 3.4 14X ~ 90X 16.4 ~ 2.5 21X ~ 135X 11 ~ 1.7 0.3X 251 2.1X ~ 13.5X 109 ~ 17 2.62X ~ 16.87X 95 ~ 14.6 3.15X ~ 20.25X 73 ~ 11.4 4.2X ~ 27X 54.7 ~ 8.5 6.3X ~ 40.5X 36.6 ~ 5.7 0.44X 171 3.08X ~ 19.8X 74.5 ~ 11.5 3.85X ~ 24.75X 64.7 ~ 10 4.62X ~ 29.7X 50 ~ 7.7 6.16X ~ 39.6X 37.2 ~ 5.9 9.24X ~ 59.4X 25 ~ 3.8 0.5X 148 3.5X ~ 22.5X 65.7 ~ 10.2 4.37X ~ 28.12X 57 ~ 8.8 5.25X ~ 33.75X 44 ~ 6.8 7X ~ 45X 32.8 ~ 5.1 10.5X ~ 67.5X 22 ~ 3.4 0.75X 97 5.25X ~ 33.75X 43.8 ~ 6.8 6.56X ~ 42.18X 38 ~ 5.8 7.87X ~ 50.62X 29.3 ~ 4.5 10.5X ~ 67.5X 21.9 ~ 3.4 15.75X ~ 101.25X 14.6 ~ 2.2 1.5X 49 10.5X ~ 67.5X 21.9 ~ 3.4 13.12X ~ 84.37X 19 ~ 2.9 15.75X ~ 101.25X 14.6 ~ 2.2 21X ~ 135X 10.9 ~ 1.7 31.5X ~ 202.5X 7.3 ~ 1.1 2.0X 33 14X ~ 90X 16.4 ~ 2.5 17.5x ~ 112.5X 14.2 ~ 2.2 21X ~ 135X 11 ~ 1.7 28X ~ 180X 8.2 ~ 1.2 42X ~ 270X 5.5 ~ 0.8 EMZ-6 0.62X~ 4.2X none 108 6.5X ~ 42X 35 ~ 5.4 8.12X ~ 52.5X 30.7 ~ 4.7 9.75X ~ 63X 23.7 ~ 3.6 13x ~ 84X 17.7 ~ 2.7 19.5X ~ 126X 11.8 ~ 1.8 0.5X 180 3.25X ~ 21X 70 ~ 10.8 4.0X ~ 26.2X 61.4 ~ 9.4 4.87X ~ 31.5X 47.4 ~ 7.2 6.5X ~ 42X 35.4 ~ 5.4 9.75X ~ 63X 23.6 ~ 3.6 Model Zoom Range Auxiliary Lens Working Distance (mm) SWF10X Eyepieces SWF12.5X Eyepieces SWF15X Eyepieces SWF20X Eyepieces SWF30X Eyepieces Total Mag. Field Diameter (mm) Total Mag. Field Diameter (mm) Total Mag. Field Diameter (mm) Total Mag. Field Diameter (mm) Total Mag. Field Diameter (mm) EMZ-10 Z-7100 0.7X~ 4.5X none 110 7X ~ 45X 32.8 ~ 5.1 8.75X ~ 56.25X 28.5 ~ 4.4 10.5X ~ 67.5X 22 ~ 3.4 14X ~ 90X 16.4 ~ 2.6 21X ~ 135X 11 ~ 1.7 0.3X 326 2.1X ~ 13.5X 109 ~ 17 2.62X ~ 16.87X 95 ~ 14.6 3.15X ~ 20.25X 73 ~ 11.3 4.2X ~ 27X 54.6 ~ 8.6 6.3X ~ 40.5X 36.6 ~ 5.7 0.44X 247 3.08X ~ 19.8X 74.5 ~ 11.5 3.85X ~ 24.75X 64.7 ~ 10 4.62X ~ 29.7X 50 ~ 7.7 6.16X ~ 39.6X 37.2 ~ 5.9 9.24X ~ 59.4X 25 ~ 3.8 0.5X 194 3.5X ~ 22.5X 65.6 ~ 10.2 4.37X ~ 28.12X 57 ~ 8.8 5.25X ~ 33.75X 44 ~ 6.8 7X ~ 45X 32.8 ~ 5.1 10.5X ~ 67.5X 22 ~ 3.4 0.75X 127 5.25X ~ 33.75X 43.8 ~ 6.8 6.56X ~ 42.18X 38 ~ 5.8 7.87X ~ 50.62X 29.3 ~ 4.5 10.5X ~ 67.5X 21.8 ~ 3.4 15.75X ~ 101.25X 14.6 ~ 2.2 1.5X 64 10.5X ~ 67.5X 21.8 ~ 3.4 13.12X ~ 84.37X 19 ~ 2.9 15.75X ~ 101.25X 14.6 ~ 2.2 21X ~ 135X 10.9 ~ 1.7 31.5X ~ 202.5X 7.3 ~ 1.1 2.0X 44 14X ~ 90X 16.4 ~ 2.5 17.5X ~ 112.5X 14.2 ~ 2.2 21X ~ 135X 11 ~ 1.7 28X ~ 180X 8.2 ~ 1.2 42X ~ 270X 5.5 ~ 0.8 EMZ-12 EMZ-12TR 0.4X~ 2.5X none 185 4X ~ 25X 57 ~ 9.2 5X ~ 31.2X 50 ~ 8 6X ~ 37.5X 38.5 ~ 6.1 8X ~ 50X 28.7 ~ 4.6 12X ~ 75X 19.2 ~ 3 0.7X 233 2.8X ~ 17.5X 82.1 ~ 13.1 3.5X ~ 21.8X 71.4 ~ 11.4 4.2X ~ 26.2X 55 ~ 8.8 5.6X ~ 35X 41 ~ 6.5 8.4X ~ 46.2X 27.5 ~ 4.4 EMZ-13 EMZ-13TR EMZ-13VX 1X~ 7.0X none 90 10X ~ 70X 22.0 ~ 3.14 12.5X ~ 87.5X 17.6 ~ 2.51 15X ~ 105X 14.66 ~ 2.09 20X ~ 140X 11.0 ~ 1.57 30X ~ 210X 7.33 ~ 1.04 0.3X 230 3X ~ 21X 73.33 ~ 10.47 3.75X ~ 26.25X 58.6 ~ 8.38 4.5X ~ 31.5X 48.88 ~ 6.98 6.0X ~ 42.0X 36.6 ~ 5.23 9.0X ~ 63.0X 24.4 ~ 3.49 0.44X 167 4.4X ~ 30.8X 50.0 ~ 7.13 5.5X ~ 38.5X 40 ~ 4.5 6.6X ~ 46.2X 33.1 ~ 4.5 8.8X ~ 61.6 25.0 ~ 3.5 13.2X ~ 92.4X 16.5 ~ 2.3 0.5X 139 5X ~ 35X 44.0 ~ 6.28 6.25X ~ 43.75X 35.2 ~ 5.02 7.5X ~ 52.5X 29.3 ~ 4.19 10X ~ 70X 22.0 ~ 3.14 15X ~ 105X 14.6 ~ 2.09 0.75X 92 7.5X ~ 52.5X 29.3 ~ 4.19 9.37X ~ 65.62X 23.47 ~ 3.35 11.25X ~ 78.75X 19.55 ~ 2.79 15X ~ 105X 14.66 ~ 2.09 22.5X ~ 157.5X 9.77 ~ 1.39 1.5X 48 15X ~ 105X 14.6 ~ 2.09 18.75X ~ 131.25X 11.73 ~ 1.67 22.5X ~ 157.5X 9.77 ~ 1.39 30X ~ 210X 7.33 ~ 1.04 45X ~ 315X 4.88 ~ 0.69 2.0X 32 20X ~ 140X 11.0 ~ 1.57 25X ~ 175X 8.8 ~ 1.25 30X ~ 210X 7.33 ~ 1.04 40x ~ 280x 5.5 ~ 0.78 60X ~ 420X 3.66 ~ 0.52 Model Zoom Range Auxiliary Lens Working Distance (mm) SWF10X Eyepieces SWF12.5X Eyepieces SWF15X Eyepieces SWF20X Eyepieces SWF30X Eyepieces Total Mag. Field Diameter (mm) Total Mag. Field Diameter (mm) Total Mag. Field Diameter (mm) Total Mag. Field Diameter (mm) Total Mag. Field Diameter (mm) EMZ-8TR EMZ-8TRD EMZ-8U EMZ-8UD EMZ-8 0.7X~ 4.5X none 104 7X ~ 45X 32.8 ~ 5.1 8.75X ~ 56.25X 28.5 ~ 4.4 10.5X ~ 67.5X 22 ~ 3.4 14X ~ 90X 16.4 ~ 2.6 21X ~ 135X 11 ~ 1.7 0.28X 300 1.96X ~ 12.6X 112.3 ~ 17.4 2.45X ~ 15.75X 97.5 ~ 15.3 2.94X ~ 18.9X 78.1 ~ 12.2 3.92X ~ 25.2X 55.6 ~ 8.7 5.88X ~ 37.8X 34 ~ 5.5 0.35X 250 2.45X ~ 15.75X 93.7 ~ 14.5 3.06X ~ 19.68X 81.4 ~ 12.5 3.67X ~ 23.62X 62.8 ~ 9.7 4.9X ~ 31.5X 46.8 ~ 7.4 7.35X ~ 47.25X 31.4 ~ 4.8 0.5X 174 3.5X ~ 22.5X 65.6 ~ 10.2 4.37X ~ 28.12X 57 ~ 8.8 5.25X ~ 33.75X 44 ~ 6.8 7X ~ 45X 32.8 ~ 5.1 10.5X ~ 67.5X 22 ~ 3.4 1.5X 57 10.5X ~ 67.5X 21.8 ~ 3.4 13.12X ~ 84.37X 19 ~ 2.9 15.75X ~ 101.25X 14.6 ~ 2.2 21X ~ 135X 10.9 ~ 1.7 31.5X ~ 202.5X 7.3 ~ 1.1
Downloads	Download EMZ-5D Product Data Sheet (PDF) Double click to read at full screenDownload Brochure (PDF) Double click to read at full screenDownload Manual (PDF) EM SERIES Video
Specifications	EMZ-5D Info: The EMZ-5D body offers detent click-stops and delivers sharp, high-contrast images and an excellent zoom range of 6.5:1 that provides exceptionally high resolution images all throughout the zoom range. The EMZ-5D employs Greenough optics, for improved image flatness and contrast. As a result images are brighter and more distinct even at the periphery of the field of view. With the large zoom range, the EMZ-5D offers high resolution observation in precision-oriented semi-conductor, medical device and routine inspection. In addition to it’s compact design and versatility a wide variety of auxiliary lenses and stands are available to allow the user to customize their desired working distance to adapt to almost any application. Body: Binocular, Rotatable 360°, Cast Aluminum Alloy Construction Zoom Ratio: 6.5:1 Zoom Range: 0.7x – 4.5x Zoom Knobs Markings: 0.7, 1, 1.5, 2, 2.5, 3, 3.5, 4, 4.5Zoom Control: Dual, detent graduated click-stops, bilateral Magnification: 7x – 45x (10x eyepieces) Objective Lens: Brass ConstructionField of View: 32mm – 5.1mm Working distance: 93mm Eyetube Inclination: 45° Eyepieces: 5x, 7.5x, 10x, 12.5x, 15x, 20x, and 30x (optional)Interpupillary Distance: 54mm – 75mm Dioptric Adjustment: Dual (+/- 5 diopters) Extended Mag Range: 2.1x – 270x (With auxiliary lenses and eyepieces) Extended Working Distances: 34mm – 251mm (With auxiliary lenses and eyepieces)Mounting: Fits 84.5mm Diameter Focus HoldersAuxiliary Lenses: 0.3x (252mm), 0.44x (181mm), 0.5x (150mm), 0.75x (97mm), 1.5x (49mm), and 2x (34mm) (optional) MA502 Info: Eyepiece: Super Wide Field 10x Eyepieces (paired), (30.5mm Outer Diameter), Field No. 23 (With 25mm reticle mount) BD-LED Info: Stand: Pole stand with 240mm (9") length by 160mm (6") wide by 280mm (11") high base with 8.5" inch pillarMA569: 94.5mm diameter glass stage plate MA593: Two stainless steel stage clipsF: Coarse focus block with 84.5mm inner diameterIllumination Port: Transmitted variable intensity LED illumination with rheostat Includes: • Binocular Body (EMZ-5D) • 10X Eyepiece (MA502) • Pole Stand (BD-LED) • Meiji Techno Dust Cover (MA703) • Rubber Eyeguards/Eyeshields (Paired) (MA600) • EMZ Meiji Techno Instruction Manual • Limited Lifetime Warranty Card Product Information:Manufacturer: MADE IN JAPAN Warranty: LIMITED LIFETIME WARRANTY OPTIONAL ILLUMINATOR ACCESSORIES RINGLIGHTS (OPTIONAL) Model MA962 MA964 MA961D/S/ESD (SLIMLINE) MA961D/40 (40 LEDs) MA961D/80/ESD (80 LEDs) MA305/100 Light Type LED LED LED LED LED Fluorescent White Light Options Daylight Daylight Daylight,Cool White, Warm White Daylight, Cool White, Warm White Daylight, Cool White, Warm White, Daylight,Warm White Number of Bulbs 56 60 40 40 80 1 Wattage 3.5W 10W 4W N/A 5W 8W Input 100V-240V 100V-240V 100V-240V 100V-240V 100V-240V 100V-240V Output 12V DC, 0.5A 10W 24V, -0.75A 18W max 24V, -0.75A 18W max 24V, -0.75A 18W max 8W Inner Diameter 57mm (2.24") 54.6mm (2.15") 66.8mm (2.63") 66.8mm (2.63") 66.8mm (2.63") 48mm (1.89") Outer Diameter 95.5mm (3.76") 90mm (3.54") 101mm (4.01") 97mm (3.81") 105mm (4.11") 90mm (3.54") Height 31.75mm (1.25") 22.8mm (0.9") 28mm (1.09") 26mm (1.02") 26mm (1.02") 15.8mm (0.662") Length 133.8mm (5.27") 90mm (3.54") 135mm (5.30") 151mm (5.94") 125mm (4.92") 109mm (4.29") Needs Adapter Mount for EMZ Series (MA302) Yes No Yes No No Yes Needs Adapter Mount for RZ Series (MA308) Yes No Yes No No Yes DUAL ARM FIBER OPTIC ILLUMINATORS (OPTIONAL) Model FL151 FT191 FL-5000-DG FQ151 FQ-5000-DG TPI6IL Light Type Halogen Halogen LED Halogen LED LED Input 115 V AC (230 V AC available) 120 V AC (230 V AC available) 110 V AC (240V available) 115 V AC (220V available) 110 V AC (220V available) 90-264 VAC Wattage 150 Watt, 21 V 150 Watt, 21V 150 Watt, 21V 150 Watt, 21V 150 Watt, 21V 5 Watt Output 1750 Lumens at fiber optic plane 200 Watt (Max) 2000+ Lumens (12.7mm aperture) 150 Watt 80 Watt 500 Lumens Fuse Type 3 Amp, 3A slow blow 2, 5 Amp slow blow 0.5A-1.2A 3Amp 2Amp N/A Color Temperature 3200K 3200K 5000K 3250K 5000K-8300K 6500K Input Fiber Diameter 15mm or 25mm (optional) 15mm or 25mm (optional) 15mm or 25mm (optional) 15.8mm (0.625") (other sizes available) 15.8mm (0.625") N/A Light Guide Length 584mm (23") self-supporting 584mm (23") self-supporting 584mm (23") self-supporting 609mm (24") obedient arm 609mm (24") obedient arm 482.60 mm (19") Active Fiber Bundle 0.20" (5mm) 0.31" (8mm) 0.20" (5mm) 0.265” (4.76mm) 0.265” (4.76mm) N/A Dimensions 6.8” (W) X 5” (H) X 8.3” (D) 8” (W) X 4.75” (H) X 7” (D) 7.0” (W) X 4.9” (H) X 8.8” (D) 7.0” (W) X 6.5” (H) X 7.5” (D) 4.75" (W) X 6" (H) X 9" (D) 4.68" (Diameter) x 19 ¾ " (L) x 2.20 (Base Height) Weight 7.75lbs 13.5lbs 6lbs 7.5lbs 7 lbs 5.25lbs ANNULAR ARM FIBER OPTIC ILLUMINATORS (OPTIONAL) Model FL152 FT192 FL-5000-RL FQ152 FQ-5000-RL Light Type Halogen Halogen LED Halogen LED Input 115 V AC (230 V AC available) 120 V AC (230 V AC available) 110 V AC (240V available) 115 V AC (220V available) 110 V AC (220V available) Wattage 150 Watt, 21 V 150 Watt, 21V 150 Watt, 21V 150 Watt, 21V 150 Watt, 21V Output 1750 Lumens at fiber optic plane 200 Watt (Max) 2000+ Lumens (12.7mm aperture) 150 Watt 80 Watt Fuse Type 3 Amp, 3A slow blow 2, 5 Amp slow blow 0.5A-1.2A 3Amp 2Amp Color Temperature 3200K 3200K 5000K 3250K 5000K-8300K Input Fiber Diameter 15mm or 25mm (optional) 15mm or 25mm (optional) 15mm or 25mm (optional) 15.8mm (0.625") (other sizes available) 15.8mm (0.625") Light Guide Length 914.4mm (36") 914.4mm (36") 914.4mm (36") 914.4mm (36") 914.4mm (36") Active Fiber Bundle 9.5mm (0.373”) 10mm (0.394") 9.5mm (0.373”) 9.45mm (0.371") 9.45mm (0.371") Diameter Ring Aperture 60.2mm (2.37") 60mm (2.36") 60.2mm (2.37") 60mm (2.36") 60mm (2.36") Dimensions 6.8” (W) X 5” (H) X 8.3” (D) 8” (W) X 4.75” (H) X 7” (D) 7.0” (W) X 4.9” (H) X 8.8” (D) 7.0” (W) X 6.5” (H) X 7.5” (D) 4.75" (W) X 6" (H) X 9" (D) Weight 7.75lbs 13.5lbs 6lbs 7.5lbs 7 lbs SINGULAR ARM FIBER OPTIC ILLUMINATORS (OPTIONAL) Model FL153 FT193 FL-5000-SG Light Type Halogen Halogen LED Input 115 V AC (230 V AC available) 120 V AC (230 V AC available) 110 V AC (240V available) Wattage 150 Watt, 21 V 150 Watt, 21V 150 Watt, 21V Output 1750 Lumens at fiber optic plane 200 Watt (Max) 2000+ Lumens (12.7mm aperture) Fuse Type 3 Amp, 3A slow blow 2, 5 Amp slow blow 0.5A-1.2A Color Temperature 3200K 3200K 5000K Input Fiber Diameter 15mm or 25mm (optional) 15mm or 25mm (optional) 15mm or 25mm (optional) Light Guide Length 457.2mm (18") 508mm (24") 457.2mm (18") Active Output Fiber Bundle 6.35mm (0.25") 6.35mm (0.25") 6.35mm (0.25") Dimensions 6.8” (W) X 5” (H) X 8.3” (D) 8” (W) X 4.75” (H) X 7” (D) 7.0” (W) X 4.9” (H) X 8.8” (D) Weight 7.75lbs 13.5lbs 6lbs
